| Your quest for matchless quality Drum Mix Asphalt Plant ends at Topcon Engineering. We furnish good quality mini asphalt drum mix plant that is manufactured from excellent quality raw materials that mark them highly reliable and dependable. Our Drum Mix Plant is known for effectual performance and easy operation. These drum plants are available in varied production capacities and can even be customized as per requirements of honored customers. We ensure easy accessibility and are recognized as one of the chief Drum Mix Plant Manufacturers, Supplier & Exporter from Gujarat (India). |
|
| TE Series |
 |
DM-35 (Capacity 30-45 t/h) |
|
|
DM-45 (Capacity 40-60 t/h) |
|
|
DM-50 (Capacity 80-100 t/h) |
|
|
DM-60 (Capacity 100-120 t/h) |
|
|
|
|
| |
|
| PLANT DESCRIPTION |
|
 |
Modern Drum Mix technology is used to produce the highest quality hot Asphalt mixture. Coating action in the drum mix produces uniform high quality hot mix with equipment that has few wearing parts and require less maintenance. |
|
|
| |
| CONTROLS |
| Aggregate is fed by a variable speed belt feeder for consistent & accurate control. Flow rates are adjusted with precision gates. Asphalt is pumped by a positive displacement pump with a variable speed drive. Flow rate of asphalt is adjustable. |
 |
|
|
| |
| COLD FEED: (4 bin aggregate feeder) |
|
 |
At the bottom of bins, adjustable gates are provided to regulate the flow of aggregate with four auxiliary conveyors. Gathering conveyor is equipped with scraper and driven by A.C. Motor. Aggregate from the Gathering conveyor is fed in to the drum by a slinger conveyor through vibrating screen. |
|
|
| |
| ASPHALT TANK |
| The inherent asphalt tank capacity of the drum mix process, along with the frame mounted dry dust collector makes this drum mixer a good neighbour. This machine has maximum asphalt tank efficiency so, wet collector is not necessary except in metropolitan areas. |
 |
|
|
| |
| DRUM |
|
 |
The 1.20 mtr. X 6.1 mtr. Drum heats the aggregate and mixes it with asphalt. Unit includes an oil burner & blower. The drum shell is made of high strength steel for a long life. Years of experience results in a flight design that optimizes efficiency and minimizes fuel usage. |
|
|
| |
|
| PORTABILITY |
| This complete plant travels in one unit including drum mixer, dry dust collector and load out conveyor. The portability makes this plant ideal for small jobs and the high capacity makes it ideal for big jobs. |
 |
|
|
| |
| CONTROL PANEL |
| All control panels for plant with small control cabins. |
|
| CONTROL PANEL CABIN |
 |
|
|
| Centralised air conditioned and insulated control cabin is provided with electronic control panel cabinet to operate the entire plant. |
|
|
|
| |
| SALIENT FEATURES |
- Easy operation and less maintenance
- Designed for the international market
- Modern Drum mix Technology
- Produces high production rate
- Portable Stationery
- Low Dust Emissions
- Proper drying and Homogeneous Mixing
- Modular Design for Containerized transport
- Proper Asphalt Coating And Saving of Aggregate
- Easy to Operate
- Less Fuel Consumption
- Fully Automatic Computerized Control Panel Board
- Accuracy in Quality Control
|
|
|
|
|
| |
 |
